Home
Motors
Stainless steel motors
B14 motor flange

B14 motor flange

Shop By

Rated output (kW)

0.12 (1)
0.18 (8)
0.25 (7)
0.37 (7)
0.55 (11)
0.75 (8)
1.1 (7)
1.5 (4)
2.2 (4)
3 (2)
4 (2)
7.5 (1)

0

✕

Poles

2 (24)
4 (25)
6 (13)

0

✕

Mounting

B14 (62)

0

✕

IEC norm

63 (10)
71 (14)
80 (18)
90 (14)
100 (4)
112 (1)
132 (1)

0

✕

BCD

200 (1)
130 (5)
115 (14)
100 (18)
85 (14)
75 (10)

0

✕

Efficiency standard

IE3 (30)
IE4 (32)

0

✕

IP classification

IP 66 (38)
IP 69K (24)

0

✕

Voltage connection (Δ/Y)

230/400 (59)
400/690 (3)

0

✕

Marlin AC motor TENV71B-4, 0.37kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TENV71B-4, 0.37kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel TENV71B-4

IP classification IP 66
Speed (RPM) 1400
Rated output (kW) 0.37
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 2.48
Mounting B14
BCD 85
Poles 4
Efficiency standard IE3
Shaft diameter (mm) Ø14
Cooling TENV

€805.62

excl. VAT

Quantity

Marlin AC motor TEFC100LB-4, 3.00kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TEFC100LB-4, 3.00kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel TEFC100LB-4

IP classification IP 66
Speed (RPM) 1400
Rated output (kW) 3
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 19.7
Mounting B14
BCD 130
Poles 4
Efficiency standard IE3
Shaft diameter (mm) Ø28
Cooling TEFC

€2,178.12

excl. VAT

Quantity

Marlin AC motor TEFC80A-2, 0.75kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TEFC80A-2, 0.75kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel TEFC80A-2

IP classification IP 66
Speed (RPM) 2800
Rated output (kW) 0.75
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 2.48
Mounting B14
BCD 100
Poles 2
Efficiency standard IE3
Shaft diameter (mm) Ø19
Cooling TEFC

€1,418.03

excl. VAT

Quantity

Marlin AC motor TEFC100LA-4, 2.20 kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TEFC100LA-4, 2.20 kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel TEFC100LA-4

IP classification IP 66
Speed (RPM) 1400
Rated output (kW) 2.2
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 14.59
Mounting B14
BCD 130
Poles 4
Efficiency standard IE3
Shaft diameter (mm) Ø28
Cooling TEFC

€2,013.97

excl. VAT

Quantity

Marlin AC motor TEFC71B-2, 0.55kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TEFC71B-2, 0.55kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel TEFC71B-2

IP classification IP 66
Speed (RPM) 2800
Rated output (kW) 0.55
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 1.85
Mounting B14
BCD 85
Poles 2
Efficiency standard IE3
Shaft diameter (mm) Ø14
Cooling TENV

€1,268.74

excl. VAT

Quantity

Marlin AC motor TEFC63A-2, 0.18kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TEFC63A-2, 0.18kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel TEFC63A-2

IP classification IP 66
Speed (RPM) 2800
Rated output (kW) 0.18
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 0.62
Mounting B14
BCD 75
Poles 2
Efficiency standard IE3
Shaft diameter (mm) Ø11
Cooling TEFC

€1,083.71

excl. VAT

Quantity

Marlin AC motor TENV80A-4Ø14, 0.55kW, 1400RPM, Ø14mm, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TENV80A-4Ø14, 0.55kW, 1400RPM, Ø14mm, 230/400V, 50Hz, IP66, stainless steel TENV80A-4Ø14

IP classification IP 66
Speed (RPM) 1400
Rated output (kW) 0.55
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 3.68
Mounting B14
BCD 100
Poles 4
Efficiency standard IE3
Shaft diameter (mm) Ø14
Cooling TENV

€996.54

excl. VAT

Quantity

Marlin AC motor TENV63B-4, 0.18kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TENV63B-4, 0.18kW, 1400RPM, 230/400V, 50Hz, IP66, stainless steel TENV63B-4

IP classification IP 66
Speed (RPM) 1400
Rated output (kW) 0.18
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 1.25
Mounting B14
BCD 75
Poles 4
Efficiency standard IE3
Shaft diameter (mm) Ø11
Cooling TEFC

€723.54

excl. VAT

Quantity

Marlin AC motor TENV71A-6, 0.18kW, 900RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TENV71A-6, 0.18kW, 900RPM, 230/400V, 50Hz, IP66, stainless steel TENV71A-6

IP classification IP 66
Speed (RPM) 900
Rated output (kW) 0.18
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 1.87
Mounting B14
BCD 85
Poles 6
Efficiency standard IE3
Shaft diameter (mm) Ø14
Cooling TENV

€847.12

excl. VAT

Quantity

Marlin AC motor TENV71A-2, B14, 0.37kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel

Marlin AC motor TENV71A-2, B14, 0.37kW, 2800RPM, 230/400V, 50Hz, IP66, stainless steel TENV71A-2

IP classification IP 66
Speed (RPM) 2800
Rated output (kW) 0.37
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 1.26
Mounting B14
BCD 85
Poles 2
Efficiency standard IE4
Shaft diameter (mm) Ø14
Cooling TENV

€815.52

excl. VAT

Quantity

Items 1-10 of 62

You're currently reading page 1
Page 2
Page 3
Page 4
Page 5

Show

Compare Products
