Home
Motors
Stainless steel motors
B5 motor flange

B5 motor flange

Shop By

Rated output (kW)

0.18 (1)
0.25 (2)
0.37 (2)
0.55 (2)
0.75 (1)
1.1 (3)
1.5 (2)
2.2 (3)
3 (1)
4 (1)
7.5 (1)

0

✕

Poles

2 (5)
4 (10)
6 (4)

0

✕

Mounting

B5 (19)

0

✕

IEC norm

63 (1)
71 (4)
80 (3)
90 (7)
100 (2)
112 (1)
132 (1)

0

✕

BCD

75 (1)
85 (1)
115 (3)
130 (6)
165 (8)

0

✕

Material

stainless steel, EN 4301 (9)
Stainless steel (10)

0

✕

IP classification

IP 66 (9)
IP 69K (10)

0

✕

Voltage connection (Δ/Y)

230/400 (16)
260/400 (1)
400/690 (2)

0

✕

Clean Geartech TENV71A-4 AC-Motor, B5, 0.25KW, 1444RPM, Stainless steel

Clean Geartech TENV71A-4 AC-Motor, B5, 0.25KW, 1444RPM, Stainless steel HV82SPMCKE4GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 1444
Rated output (kW) 0.25
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 1.66
Mounting B5
IEC norm 71
BCD 130
Poles 4
Shaft diameter (mm) 14
Cooling TENV

€728.78

excl. VAT

Quantity

Clean Geartech TENV71B-6 AC-Motor, B5, 0.25KW, 890RPM, 230/400, Stainless steel

Clean Geartech TENV71B-6 AC-Motor, B5, 0.25KW, 890RPM, 230/400, Stainless steel HV82SPMCKE6GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 890
Rated output (kW) 0.25
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 2.65
Mounting B5
IEC norm 71
BCD 130
Poles 6
Shaft diameter (mm) 14
Cooling TENV

€768.05

excl. VAT

Quantity

Clean Geartech TENV71B-4 AC-Motor, B5, 0.37KW, 1440RPM, 230/400, Stainless steel

Clean Geartech TENV71B-4 AC-Motor, B5, 0.37KW, 1440RPM, 230/400, Stainless steel HV82SPMCKF4GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 1440
Rated output (kW) 0.37
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 2.45
Mounting B5
IEC norm 71
BCD 130
Poles 4
Shaft diameter (mm) 14
Cooling TENV

€758.53

excl. VAT

Quantity

Clean Geartech TENV80A-4 AC-Motor, B5, 0.55KW, 1448RPM, 230/400, Stainless steel

Clean Geartech TENV80A-4 AC-Motor, B5, 0.55KW, 1448RPM, 230/400, Stainless steel HV82SPMDKG4GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 1448
Rated output (kW) 0.55
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 3.66
Mounting B5
IEC norm 80
BCD 165
Poles 4
Shaft diameter (mm) 19
Cooling TENV

€880.22

excl. VAT

Quantity

Clean Geartech TENV80B-6 AC-Motor, B5, 0.55KW, 900RPM, 230/400, Stainless steel

Clean Geartech TENV80B-6 AC-Motor, B5, 0.55KW, 900RPM, 230/400, Stainless steel HV82SPMDKG6GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 900
Rated output (kW) 0.55
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 5.3
Mounting B5
IEC norm 80
BCD 165
Poles 6
Shaft diameter (mm) 19
Cooling TENV

€933.56

excl. VAT

Quantity

Clean Geartech TENV80B-4 AC-Motor, B5, 0.75KW, 1456RPM, Stainless steel

Clean Geartech TENV80B-4 AC-Motor, B5, 0.75KW, 1456RPM, Stainless steel HV82SPMDKH4GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 1456
Rated output (kW) 0.75
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 4.95
Mounting B5
IEC norm 80
BCD 165
Poles 4
Shaft diameter (mm) 19
Cooling TENV

€943.20

excl. VAT

Quantity

Clean Geartech TENV90S-4 AC-Motor, B5, 1.1KW, 1475RPM, 230/400, Stainless steel

Clean Geartech TENV90S-4 AC-Motor, B5, 1.1KW, 1475RPM, 230/400, Stainless steel HV82SPMEKI4GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 1475
Rated output (kW) 1.1
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 7.15
Mounting B5
IEC norm 90
BCD 165
Poles 4
Shaft diameter (mm) 24
Cooling TENV

€1,221.42

excl. VAT

Quantity

Clean Geartech TENV90L-6 AC Motor, B5, 1.1KW, 950RPM, Stainless steel

Clean Geartech TENV90L-6 AC Motor, B5, 1.1KW, 950RPM, Stainless steel HV82SPMEKI6GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 950
Rated output (kW) 1.1
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 11.1
Mounting B5
IEC norm 90
BCD 165
Poles 6
Shaft diameter (mm) 24
Cooling TENV

€1,312.95

excl. VAT

Quantity

Clean Geartech TENV90S-2 AC Motor, B5, 1.5KW, 2930RPM, Stainless steel

Clean Geartech TENV90S-2 AC Motor, B5, 1.5KW, 2930RPM, Stainless steel HV82SPMEKK2GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 2930
Rated output (kW) 1.5
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 4.9
Mounting B5
IEC norm 90
BCD 165
Poles 2
Shaft diameter (mm) 24
Cooling TENV

€1,212.71

excl. VAT

Quantity

Clean Geartech TENV90L-2 AC-Motor, B5, 2.2KW, 2920RPM, Stainless steel

Clean Geartech TENV90L-2 AC-Motor, B5, 2.2KW, 2920RPM, Stainless steel HV82SPMEKL2GTENN4KSA1-N---NNN

IP classification IP 69K
Speed (RPM) 2920
Rated output (kW) 2.2
Voltage connection (Δ/Y) 230/400
Nominal torque (Nm) 7.2
Mounting B5
IEC norm 90
BCD 165
Poles 2
Shaft diameter (mm) 24
Cooling TENV

€1,295.67

excl. VAT

Quantity

Items 1-10 of 19
