Hydro-Mec 030, worm gear Ø14 hollow shaft, 20:1, input 56B14, aluminium
HV80P030FB04C0-OB3-AFeaturing a gear size of 030, this unit delivers a ratio of 20:1 with an input interface of 56B14. The input shaft diameter is 9 mm, while the output shaft diameter is 14 mm. With an operational efficiency of 70%, it supports both BCD input and output of 65. The gearbox housing is made from aluminium, ensuring a lightweight yet robust construction suitable for diverse environments. Ideal for use in automated systems, conveyors, and electromechanical assemblies.
Specifications
Product description
Downloads
€138.00
Made to order
Expected shipment:
Loading...
Accessories
More Information
HS-Code
84834025.000000
Material
Aluminium
Ratio
20:1
BCD input
65
BCD output
65
Efficiency (%)
70
Gear output shaft (mm)
14
Gear input shaft (mm)
9
Gear motor interface
56B14
Gear size
030
Output speed at 1400 RPM
70
Max output torque (Nm)
19
Max kW input at 1400 rpm
0.2
Mounting position
B3
Oil
Telium VSF 320
Producer
Hydro-Mec
Description
Brand description:Hydro-Mec is a renowned Italian manufacturer of gearboxes and drive components, known for combining modular design with precision engineering. With a focus on durability, innovation, and configurable gear solutions, Hydro-Mec is a trusted brand among technical specialists within industrial automation, mechanical engineering, and manufacturing sectors.Key features and application advantages:
High-precision 20:1 gear ratio enables optimal torque multiplication, making it ideal for applications requiring speed reduction and increased output torque, such as conveyor drives, packaging equipment, or lifting mechanisms.
Aluminium gearbox housing offers lightweight construction coupled with corrosion resistance, making it suitable for dynamic positioning systems, food handling machinery, and automated guided vehicles where material weight and longevity are critical.
Output shaft diameter Ø14 mm provides compatibility with a wide range of coupling systems and mechanical linkages, ensuring ease of integration in custom machinery setups.
Compact size – Gearbox type 030 – is tailored for installations with limited space and weight constraints, such as mobile machinery, robotics, and decentralized drive systems.
70% operational efficiency ensures minimal energy loss, supporting energy-conscious industries such as renewable energy equipment and high-duty cycle systems.
IEC-compatible motor flange interface (size 56B14) allows for seamless motor integration, promoting modular design and faster maintenance cycles in assembly lines and automation cells.
9 mm input shaft ensures reliable coupling with small to medium motor drives, supporting linear actuators, indexing mechanisms, and small-scale conveyor systems.
Ø14 mm hollow output shaft (Stainless Steel) provides added rust resistance for use in humid or corrosive environments, such as water treatment plants and chemical processing lines. Hydro-Mec’s 030 worm gear solution combines compact design and industrial-grade performance for applications where space, reliability, and robustness are vital.
High-precision 20:1 gear ratio enables optimal torque multiplication, making it ideal for applications requiring speed reduction and increased output torque, such as conveyor drives, packaging equipment, or lifting mechanisms.
Aluminium gearbox housing offers lightweight construction coupled with corrosion resistance, making it suitable for dynamic positioning systems, food handling machinery, and automated guided vehicles where material weight and longevity are critical.
Output shaft diameter Ø14 mm provides compatibility with a wide range of coupling systems and mechanical linkages, ensuring ease of integration in custom machinery setups.
Compact size – Gearbox type 030 – is tailored for installations with limited space and weight constraints, such as mobile machinery, robotics, and decentralized drive systems.
70% operational efficiency ensures minimal energy loss, supporting energy-conscious industries such as renewable energy equipment and high-duty cycle systems.
IEC-compatible motor flange interface (size 56B14) allows for seamless motor integration, promoting modular design and faster maintenance cycles in assembly lines and automation cells.
9 mm input shaft ensures reliable coupling with small to medium motor drives, supporting linear actuators, indexing mechanisms, and small-scale conveyor systems.
Ø14 mm hollow output shaft (Stainless Steel) provides added rust resistance for use in humid or corrosive environments, such as water treatment plants and chemical processing lines. Hydro-Mec’s 030 worm gear solution combines compact design and industrial-grade performance for applications where space, reliability, and robustness are vital.
