Key features:

• Adjustment range: The torque limiter has an adjustable range of 0.2 to 1.5 Nm, allowing for precise torque settings to meet specific requirements.
• Conical clamping assemblies: Two conical clamping assemblies with six tightening screws each ensure a secure and reliable connection, minimizing the risk of slippage or loosening during operation.
• Safety system: The torque limiter incorporates a spring-loaded ball-detent principle, providing an additional layer of safety by ensuring quick and reliable disengagement when necessary.

Specifications:

• Functional system: The torque limiter operates in a single position with automatic re-engagement as the standard mode, allowing for seamless operation and increased productivity.
• Temperature range: Operable range from -30°C to +100°C (-22°F to +212°F), ensuring reliable performance in challenging environments.

Design and Materials:

• Bellows material: High-grade stainless steel for excellent corrosion resistance
• Safety system material: Hardened steel for superior strength and reliability
• Clamping hubs material: Lightweight aluminum for easy installation and reduced weight

Bore specifications:

• Bore D1: Ø12mm H7
• Bore D2: Ø12mm H7
