Poggi right angle gearbox 2031, R1:1, D1/2, Ø19h7, 3-way, Aluminium
HV3042031111The Poggi right angle gearbox 2031 features a 1:1 gear ratio in a D1/2 configuration with three Ø19h7 shafts, offering flexibility for mirrored-output or triple-shaft applications. Rated at 38.0 Nm @ 1400 RPM and supporting up to 3000 RPM, this gearbox is designed for fast-paced industrial automation requiring precise synchronization. The aluminium housing ensures lightweight durability, while the backlash range of 15'–30' allows consistent and accurate operation under dynamic loads.
Made to order
Expected shipment:
More Information
Description
Poggi’s 2031 is ideal when you need a 3-way layout with a 1:1 gear ratio and Ø19h7 shaft interfaces (D1/2). Housed in corrosion-resistant aluminium that balances strength, low weight, and heat efficiency. Internally equipped with spiral bevel gears, it ensures smooth, low-noise, and efficient torque transfer. Fully sealed and lubricated for life, this gearbox delivers long-lasting, maintenance-free performance in high-cycle production environments.
-
Gear type: Right angle gearbox
-
Model: Poggi 2031
-
Gear ratio: 1:1
-
Shaft configuration: D1/2 (3 shafts)
-
Shaft diameter: Ø19h7
-
Max torque @ 1400 RPM: 38.0 Nm
-
Max speed: 3000 RPM
-
Housing material: Aluminium
-
Backlash: Normal 15'–30'
-
Brand: Poggi (Italy)
