Poggi right angle gearbox 2030, R1:1, D2, Ø19h7, 2-way, Aluminium
HV3042030112The Poggi right angle gearbox 2030 combines a 1:1 gear ratio with a D2 configuration, supporting dual-output configurations via two Ø19h7 shafts. With a performance rating of 38.0 Nm @ 1400 RPM and a maximum speed of 3000 RPM, this unit is ideal for mirrored drive systems, OEM machinery, or automated setups requiring precision under dynamic loads. The lightweight aluminium housing offers corrosion resistance and compactness. A backlash range of 15'–30' supports consistent and reliable motion synchronization.
Made to order
Expected shipment:
More Information
Description
Poggi’s 2030 is ideal when you need a 2-way layout with a 1:1 gear ratio and Ø19h7 shaft interfaces (D2). Featuring a compact and robust aluminium casing that balances strength, low weight, and heat efficiency. Internally equipped with spiral bevel gears, it ensures smooth, low-noise, and efficient torque transfer. Fully sealed and lubricated for life, this gearbox delivers long-lasting, maintenance-free performance in high-cycle production environments.
-
Gear type: Right angle gearbox
-
Model: Poggi 2030
-
Gear ratio: 1:1
-
Shaft configuration: D2 (2 shafts)
-
Shaft diameter: Ø19h7
-
Max torque @ 1400 RPM: 38.0 Nm
-
Max speed: 3000 RPM
-
Housing material: Aluminium
-
Backlash: Normal 15'–30'
-
Brand: Poggi (Italy)
