Description
Key features:
- Hygienic design: Designed to meet the stringent requirements of the food industry and other demanding environments.
- Extra narrow size: Compact and space-saving design, suitable for applications with limited space.
- Set screw lock: Provides a secure and reliable fit, ensuring minimal slippage and enhanced stability.
- Sealed for protection: Comes with NBR sealings, offering protection against contaminants and extending the bearing's lifespan.
- No surface coating required: The stainless steel construction eliminates the need for additional coatings, making it suitable for clean and hygienic environments.
Materials:
- Stainless steel housings (AISI 304): The housing is constructed from stainless steel.
- Stainless steel bearings (AISI 440C): The bearings are made from stainless steel, specifically AISI 440C.
Specifications
Grease nipple
None
Hole distance (mm)
95
Shaft size (mm)
Ø35
Cover
Open
Sealing
Nitrile rubber (NBR)
Bearing material
Stainless steel
Model
MKFL
Mounting
Set screw
Housing type
2-bolt flange bearing
House material
Stainless steel
Downloads
Foreign trade
HS-Code
84832000
ERP net weight (Kg)
0.50
Country of origin
CHN
