Key features:

• Radial assembly: The coupling features a radial assembly design, allowing easy mounting and adjustment of shafts before coupling assembly. This ensures efficient installation and alignment.
• Shaft misalignment compensation: The KBE2H coupling effectively compensates for shaft misalignment, accommodating angular, parallel, and axial misalignments. This feature helps reduce stress and wear on connected equipment, prolonging their lifespan.
• Axial pluggable: The coupling is axially pluggable, enabling quick and hassle-free maintenance and replacement without the need to disassemble other components.

Materials:

• Split hubs: The coupling's hubs are constructed from durable stainless steel, ensuring excellent strength and corrosion resistance. The split hub design enables easy mounting and adjustment of the shafts.
• Spider element: The coupling's spider element is made from durable polyurethane with a 98 Shore hardness rating. This material provides optimal flexibility, shock absorption, and torque transmission while ensuring long-lasting performance.

Bore epecifications:

• Bore D1: Ø15mm H7 with keyway
• Bore D2: Ø20mm H7 with keyway
