Hydro-Mec 085, worm gear Ø35 SS hollow shaft, 67:1, input 90B14, aluminium
HV80P085FB10I0-TB3-E-OFThe Hydro-Mec 085 Worm Gearbox Ø35 Stainless Steel Hollow Shaft, 67:1, Input 90B14, Aluminium is engineered for industrial power transmission applications. It features a gear ratio of 67:1 and a gear size of 085, offering reliable torque reduction. The gear input shaft diameter is 24 mm, while the gear output shaft diameter is 35 mm. Equipped with a stainless steel hollow output shaft, it ensures durability in demanding environments. The gear housing is made of aluminium, contributing to reduced weight and corrosion resistance. The unit supports a 90B14 motor interface, with an input BCD of 115 mm and an output BCD of 130 mm. Efficiency is 65%.
Specifications
Product description
Downloads
€905.00
Made to order
Expected shipment:
Loading...
Accessories
More Information
HS-Code
84834025.000000
Material
Aluminium
Ratio
67:1
BCD input
115
BCD output
130
Efficiency (%)
65
Gear output shaft (mm)
35
Gear input shaft (mm)
24
Gear input shaft (inch)
115
Gear motor interface
90B14
Gear size
085
Output speed at 1400 RPM
21
Max output torque (Nm)
289
Max kW input at 1400 rpm
0.97
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Hydro-Mec
Description
Hydro-Mec is a trusted European manufacturer known for producing high-performance and modular gear solutions. With a strong focus on engineering precision, Hydro-Mec gearboxes are widely implemented in demanding industrial environments, offering reliable performance and minimal maintenance requirements. The Hydro-Mec 085 worm gearbox combines compact design with high torque transmission, making it ideal for technical engineers and industrial specialists seeking a durable and versatile drive solution.Key Features & Application Benefits:
Stainless Steel Ø35 mm Hollow Output Shaft – Provides excellent corrosion resistance, ideal for environments with high humidity, aggressive chemicals, or food-grade requirements.
67:1 Gear Ratio – Enables high torque output at low speeds, well-suited for conveyors, mixers, material handling systems, and other high-load applications.
90B14 Gear Motor Interface – Designed for easy integration with standardized IEC motors, simplifying installation and enhancing system compatibility.
Aluminium Housing – Lightweight yet durable construction ensures optimal thermal dissipation and corrosion resistance, reducing overall system weight.
Input Shaft Dimensions Ø24 mm – Standardized dimension offers compatibility across various power transmission setups, easing mechanical interfacing.
Hydro-Mec’s Modular Design – Allows for interchangeability of components, reducing downtime and promoting flexible customization for specific industrial processes.
Efficiency of 65% – Efficient torque transfer suitable for medium-duty tasks while maintaining energy efficiency in continuous operation.
085 Gearbox Frame Size – Compact footprint enables deployment in space-constrained assembly systems and machinery, without sacrificing performance.Typical Use Cases:
Automated manufacturing lines requiring compact and reliable motion control in limited spaces.
Food processing or pharmaceutical equipment thanks to the stainless steel output shaft's hygienic properties.
Material handling systems, such as conveyor belts and hoists, benefitting from high torque and robust construction.
Packaging machinery and bottling systems demanding durability combined with lightweight performance.
Stainless Steel Ø35 mm Hollow Output Shaft – Provides excellent corrosion resistance, ideal for environments with high humidity, aggressive chemicals, or food-grade requirements.
67:1 Gear Ratio – Enables high torque output at low speeds, well-suited for conveyors, mixers, material handling systems, and other high-load applications.
90B14 Gear Motor Interface – Designed for easy integration with standardized IEC motors, simplifying installation and enhancing system compatibility.
Aluminium Housing – Lightweight yet durable construction ensures optimal thermal dissipation and corrosion resistance, reducing overall system weight.
Input Shaft Dimensions Ø24 mm – Standardized dimension offers compatibility across various power transmission setups, easing mechanical interfacing.
Hydro-Mec’s Modular Design – Allows for interchangeability of components, reducing downtime and promoting flexible customization for specific industrial processes.
Efficiency of 65% – Efficient torque transfer suitable for medium-duty tasks while maintaining energy efficiency in continuous operation.
085 Gearbox Frame Size – Compact footprint enables deployment in space-constrained assembly systems and machinery, without sacrificing performance.Typical Use Cases:
Automated manufacturing lines requiring compact and reliable motion control in limited spaces.
Food processing or pharmaceutical equipment thanks to the stainless steel output shaft's hygienic properties.
Material handling systems, such as conveyor belts and hoists, benefitting from high torque and robust construction.
Packaging machinery and bottling systems demanding durability combined with lightweight performance.
