Hydro-Mec 050, worm gear Ø25 SS hollow shaft, 26:1, input 71B14, aluminium
HV80P050FB05I0QB3-C-OFThe Hydro-Mec 050 worm gearbox Ø25 SS hollow shaft, 26:1, input 71B14, aluminium is designed for compact power transmission systems requiring corrosion-resistant output. It features a gear size of 050 and a gear ratio of 26:1, delivering 69% efficiency under rated conditions. The input shaft diameter is 14 mm, while the output shaft is a Ø25 mm stainless steel hollow shaft, providing durability in demanding environments. The gear housing is aluminium, reducing weight without compromising strength. The gear motor interface is 71B14, ensuring compatibility with standard motor mounts. This unit has a BCD input of 85 mm and a BCD output of 94 mm.
Specifications
Product description
Downloads
€324.00
Made to order
Expected shipment:
Loading...
Accessories
More Information
HS-Code
84834025.000000
Material
Aluminium
Ratio
26:1
BCD input
85
BCD output
94
Efficiency (%)
69
Gear output shaft (mm)
25
Gear input shaft (mm)
14
Gear motor interface
71B14
Gear size
050
Output speed at 1400 RPM
54
Max output torque (Nm)
66
Max kW input at 1400 rpm
0.54
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Hydro-Mec
Description
Brand Description:
Hydro-Mec is a leading European manufacturer of modular gearboxes, known for its innovative engineering, superior quality, and quick delivery. With a strong focus on flexibility and customization, Hydro-Mec supplies gear solutions suitable for demanding industrial environments and integrates Italian precision with global standards.Key Features, Benefits, and Applications:
Stainless Steel Ø25 mm Hollow Output Shaft – Provides high corrosion resistance, ideal for applications in food processing, chemical industries, and outdoor or washdown environments.
Aluminium Housing – Lightweight yet durable, offering excellent heat dissipation and corrosion resistance, suitable for mobile systems or installations with weight constraints.
Compact Gear Size 050 – Enables easy integration into space-sensitive designs in material handling, packaging, and compact automation systems.
High Torque Transmission with 26:1 Ratio – Delivers effective speed reduction and torque multiplication for precise motion control in conveyors, lifts, and positioning equipment.
Input Shaft Ø14 mm – Compatible with most standard motor couplings, ensuring flexible system integration.
Motor Interface 71B14 – Ready for fast and secure mounting with IEC-standard motors, simplifying installation and maintenance in industrial automation.
Efficiency Rating of 69% – Ensures reliable performance in continuous-duty operations such as pumps, mixing systems, and drive systems for automated machinery.
Worm Gear Design – Allows for self-locking capabilities in certain configurations, enhancing safety in vertical or load-bearing mechanisms.Applications:
Ideal for use in conveyor systems, automated production lines, washdown environments, pharmaceutical mixers, food processing machinery, and other industrial devices requiring robust, precise, and space-efficient gear solutions.
Hydro-Mec is a leading European manufacturer of modular gearboxes, known for its innovative engineering, superior quality, and quick delivery. With a strong focus on flexibility and customization, Hydro-Mec supplies gear solutions suitable for demanding industrial environments and integrates Italian precision with global standards.Key Features, Benefits, and Applications:
Stainless Steel Ø25 mm Hollow Output Shaft – Provides high corrosion resistance, ideal for applications in food processing, chemical industries, and outdoor or washdown environments.
Aluminium Housing – Lightweight yet durable, offering excellent heat dissipation and corrosion resistance, suitable for mobile systems or installations with weight constraints.
Compact Gear Size 050 – Enables easy integration into space-sensitive designs in material handling, packaging, and compact automation systems.
High Torque Transmission with 26:1 Ratio – Delivers effective speed reduction and torque multiplication for precise motion control in conveyors, lifts, and positioning equipment.
Input Shaft Ø14 mm – Compatible with most standard motor couplings, ensuring flexible system integration.
Motor Interface 71B14 – Ready for fast and secure mounting with IEC-standard motors, simplifying installation and maintenance in industrial automation.
Efficiency Rating of 69% – Ensures reliable performance in continuous-duty operations such as pumps, mixing systems, and drive systems for automated machinery.
Worm Gear Design – Allows for self-locking capabilities in certain configurations, enhancing safety in vertical or load-bearing mechanisms.Applications:
Ideal for use in conveyor systems, automated production lines, washdown environments, pharmaceutical mixers, food processing machinery, and other industrial devices requiring robust, precise, and space-efficient gear solutions.
