Description
Key features:
- Hygienic design suitable for the food industry
- Easy installation with SUC stainless steel bearings and set screw locking
- Adjustable pre-lubricated stainless steel ball bearing
- Re-lubrication options: stainless steel grease-nipple or quick coupler
- Rotary shaft seal ring (TC) with extra dust-protection lip of NBR rubber
- Stainless-steel spring for enhanced durability
- Screw set lock for secure mounting
- Maintenance-free operation, except for regular greasing when needed
- Wide operating temperature range from -20°C to +120°C
- No surface coating required, ensuring longevity and cleanliness
Materials:
- Stainless steel housings made from AISI 304
- SUC stainless steel bearings crafted from AISI 440C
- Stainless steel grease nipple for seamless lubrication
Specifications
Grease nipple
Straight
Hole distance (mm)
144
Shaft size (mm)
Ø40
Cover
Open
Sealing
Nitrile rubber (NBR)
Bearing material
Stainless steel
Model
SFL
Mounting
Set screw
Housing type
2-bolt flange bearing
House material
Stainless steel
Downloads
Foreign trade
HS-Code
84832000
ERP net weight (Kg)
1.48
Country of origin
CHN
