Description
Key features:
- Screw set lock ensures secure and stable mounting.
- Maintenance-free operation, except for periodic greasing when necessary.
- Wide operating temperature range from -20°C to +120°C.
- No surface coating required.
Materials:
- Stainless steel housings (AISI 304) offer corrosion resistance and durability, ensuring long-lasting performance.
- SUC stainless steel bearings (AISI 440C) provide high load capacity and resistance to wear and tear.
- Stainless steel grease nipple enables easy re-lubrication.
Specifications
Grease nipple
Straight
Hole distance (mm)
102
Shaft size (mm)
Ø40
Cover
Open
Sealing
Nitrile rubber (NBR)
Bearing material
Stainless steel
Model
SF
Mounting
Set screw
Housing type
4-bolt flange bearing
House material
Stainless steel
Downloads
Foreign trade
HS-Code
84832000
ERP net weight (Kg)
1.88
Country of origin
CHN
