Description
Key features:
- Screw set lock: Ensures secure and stable mounting, preventing any unwanted movement or displacement.
- Maintenance-free operation: Except for regular greasing when needed, this bearing unit requires minimal maintenance.
- Wide operating temperature range: -20°C to +120°C.
- Surface coating-free: No surface coating is necessary, thanks to the high-quality stainless steel construction.
Materials:
- Stainless steel housings (AISI 304): The robust stainless steel housings offer durability and corrosion resistance.
- SUC stainless steel bearings (AISI 440C): The high-grade stainless steel bearings provide performance and reliability.
- Stainless steel grease nipple: The included stainless steel grease nipple allows for easy re-lubrication.
Specifications
Grease nipple
Straight
Hole distance (mm)
70
Shaft size (mm)
Ø25
Cover
Closed
Sealing
Nitrile rubber (NBR)
Bearing material
Stainless steel
Model
SF
Mounting
Set screw
Housing type
4-bolt flange bearing
House material
Stainless steel
Downloads
Foreign trade
HS-Code
84832000
ERP net weight (Kg)
0.84
Country of origin
CHN
