Features:

• Easy mounting: The coupling is designed for simple and hassle-free installation, reducing downtime and increasing operational efficiency.
• High concentricity: The two concentrically machined hubs with curved jaws ensure optimal alignment and precise power transmission, minimizing the risk of misalignment-related issues.
• Vibration damping: The elastomer insert effectively dampens vibrations and shocks, protecting connected equipment and improving overall system performance.

Specifications:

• Elastomer type: Type B with a shore hardness of 64 Sh D, providing a balanced combination of flexibility and durability.
• Temperature range: The coupling can operate within a temperature range of -30 °C to +120 °C, making it suitable for various operating conditions.
• Hub material: The hubs are made from high-strength aluminum, ensuring robustness and long-lasting performance.
• Elastomer insert material: The elastomer insert is crafted from wear-resistant and thermally stable TPU, enhancing the coupling's durability and reliability.

Bore Specifications:

• Bore D1: Ø14mm H7
• Bore D2: Ø19mm H7
