Clean-Geartech X74N, helical bevel gear Ø40H7 hollow shaft, 74,79:1, input 71B14, B3, stainless steel
HV82PX74NI01-FFBN-QB3-C-OFKey features include a gear ratio of 74.79:1, 92% efficiency, and a four-stage gear configuration. The gear input shaft measures 14 mm and connects via a B14 motor interface (size 71). The output shaft is a Ø40H7 hollow shaft optimized for accurate torque transmission.Constructed from stainless steel AISI 316L, the gears ensure durability in aggressive or wash-down environments. The gear size is X74N, with input BCD 85 mm and output BCD 130 mm, supporting standardized integration across systems.
Specifications
Product description
Downloads
€4,298.00
Made to order
Expected shipment:
Loading...
Accessories
More Information
IP classification
IP66
HS-Code
84834021.000000
Material
Stainless steel AISI 316L
Ratio
74,79:1
BCD input
85
BCD output
130
Gear stages
4
Efficiency (%)
92
Gear output shaft (mm)
40
Gear input shaft (mm)
14
Gear motor interface
71B14
Gear size
X74N
Output speed at 1400 RPM
18.7
Max output torque (Nm)
675
Max kW input at 1400 rpm
1.4
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description
Brand Description: Clean-Geartech is a leading manufacturer specializing in hygienic and corrosion-resistant gear solutions for demanding industrial applications. Designed for environments requiring the highest standards in cleanliness and durability, Clean-Geartech products are particularly suited for food processing, pharmaceutical, and chemical industries. With a strong focus on stainless steel precision engineering, Clean-Geartech gears ensure reduced downtime, long service life, and optimal performance under harsh conditions.Product Description:
High corrosion resistance due to fully machined housing and components in AISI 316L stainless steel – ideal for use in food, pharmaceutical, marine, and washdown environments.
Precision-engineered Ø40H7 hollow output shaft in stainless steel offers accurate torque transmission and compatibility with hygienic drive components.
4-stage gear configuration with a ratio of 74.79:1 delivers high torque at low output speeds – suitable for conveyors, agitators, mixers, and process lines requiring intense torque multiplication.
Compatible with IEC motor mounting interface 71B14 – allows for seamless integration with standard motor sizes across automated industrial systems.
Input shaft diameter of 14 mm ensures secure coupling with a range of motors or drive units, providing versatility in mechanical design.
High mechanical efficiency of 92% reduces energy losses, improving system performance and lowering operational costs in continuous-duty applications.
Compact gear size (X74N) makes it ideal for applications with space constraints without compromising torque output.
BCD input of 85 mm and BCD output of 130 mm offer standardized mounting dimensions for easy interchangeability and integration into machinery frameworks.
Hygienic, easy-to-clean surface minimizes risk of contamination and supports CIP/SIP protocols for compliant operations in regulated environments.
Reliable for applications in harsh industrial settings requiring durability, low maintenance, and resistance to aggressive cleaning agents and chemicals.
High corrosion resistance due to fully machined housing and components in AISI 316L stainless steel – ideal for use in food, pharmaceutical, marine, and washdown environments.
Precision-engineered Ø40H7 hollow output shaft in stainless steel offers accurate torque transmission and compatibility with hygienic drive components.
4-stage gear configuration with a ratio of 74.79:1 delivers high torque at low output speeds – suitable for conveyors, agitators, mixers, and process lines requiring intense torque multiplication.
Compatible with IEC motor mounting interface 71B14 – allows for seamless integration with standard motor sizes across automated industrial systems.
Input shaft diameter of 14 mm ensures secure coupling with a range of motors or drive units, providing versatility in mechanical design.
High mechanical efficiency of 92% reduces energy losses, improving system performance and lowering operational costs in continuous-duty applications.
Compact gear size (X74N) makes it ideal for applications with space constraints without compromising torque output.
BCD input of 85 mm and BCD output of 130 mm offer standardized mounting dimensions for easy interchangeability and integration into machinery frameworks.
Hygienic, easy-to-clean surface minimizes risk of contamination and supports CIP/SIP protocols for compliant operations in regulated environments.
Reliable for applications in harsh industrial settings requiring durability, low maintenance, and resistance to aggressive cleaning agents and chemicals.
