Description
**Brand Description:** Clean-Geartech is a trusted manufacturer specializing in hygienic, high-performance gear solutions crafted for demanding environments, including food processing, pharmaceuticals, marine applications, and chemical industries. Each component is engineered with durability, corrosion resistance, and reliability in mind — making Clean-Geartech a preferred brand among engineers and technical specialists worldwide.**Technical Specifications & Key Functional Features:**
Constructed in acid-proof AISI 316L stainless steel, offering superior corrosion resistance — ideal for chemically aggressive or hygienic environments.
Equipped with a robust Ø40H7 stainless steel hollow output shaft (SS), suitable for direct shaft mounting and torque-intensive applications.
Features a high reduction ratio of 163.02:1 across 4 precision-machined gear stages — optimized for low-speed, high-torque demands in process equipment.
Delivers up to 92% mechanical efficiency, minimizing energy losses and reducing total cost of ownership through operational savings.
Input shaft dimensioned at Ø14 mm, compatible with standard IEC motors for easy installation and system integration.
Gear motor interface: 71B14 flange; widely used in automation and compact systems for its space-efficient inline mount structure.
Gear size X74N — a compact yet powerful configuration, ideal for use in tight mechanical environments requiring high torque density.
BCD Input: 85 mm, BCD Output: 130 mm — supports standard mounting applications in automation, conveyor technology, and machine construction.
Hygienic design with smooth surfaces — facilitates easy cleaning, making it suited for applications in the food & beverage sector and cleanrooms.
Bevel gearing ensures reliable torque transmission at 90 degrees, ideal for directional motion changes in compact mechanical designs. **Application Possibilities:**
Perfect for conveyors, mixers, and packaging equipment in food production requiring stainless materials and washdown-capable components.
Widely applicable in pharmaceutical process machines needing contaminant-free and chemically inert mechanical power transmission.
Excellent for marine or coastal installations where salt and humidity require maximum corrosion-resistance and long-term reliability.
Reliable solution for chemical dosing systems and agitators exposed to aggressive agents and demanding continuous operations.
Constructed in acid-proof AISI 316L stainless steel, offering superior corrosion resistance — ideal for chemically aggressive or hygienic environments.
Equipped with a robust Ø40H7 stainless steel hollow output shaft (SS), suitable for direct shaft mounting and torque-intensive applications.
Features a high reduction ratio of 163.02:1 across 4 precision-machined gear stages — optimized for low-speed, high-torque demands in process equipment.
Delivers up to 92% mechanical efficiency, minimizing energy losses and reducing total cost of ownership through operational savings.
Input shaft dimensioned at Ø14 mm, compatible with standard IEC motors for easy installation and system integration.
Gear motor interface: 71B14 flange; widely used in automation and compact systems for its space-efficient inline mount structure.
Gear size X74N — a compact yet powerful configuration, ideal for use in tight mechanical environments requiring high torque density.
BCD Input: 85 mm, BCD Output: 130 mm — supports standard mounting applications in automation, conveyor technology, and machine construction.
Hygienic design with smooth surfaces — facilitates easy cleaning, making it suited for applications in the food & beverage sector and cleanrooms.
Bevel gearing ensures reliable torque transmission at 90 degrees, ideal for directional motion changes in compact mechanical designs. **Application Possibilities:**
Perfect for conveyors, mixers, and packaging equipment in food production requiring stainless materials and washdown-capable components.
Widely applicable in pharmaceutical process machines needing contaminant-free and chemically inert mechanical power transmission.
Excellent for marine or coastal installations where salt and humidity require maximum corrosion-resistance and long-term reliability.
Reliable solution for chemical dosing systems and agitators exposed to aggressive agents and demanding continuous operations.
Specifications
IP classification
IP66
Country of origin
ITA
HS-Code
84834021.000000
ERP net weight (Kg)
0.000000
Material
Stainless steel AISI 316L
Ratio
163,02:1
BCD input
85
BCD output
130
Gear stages
4
Efficiency (%)
92
Gear output shaft (mm)
40
Gear input shaft (mm)
14
Gear motor interface
71B14
Gear size
X74N
Output speed at 1400 RPM
8.6
Max output torque (Nm)
675
Max kW input at 1400 rpm
0.66
Mounting position
V5
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834021
ERP net weight (Kg)
0.00
Country of origin
ITA
