Clean-Geartech X63N, helical bevel gear Ø35H7 hollow shaft, 77,23:1, input 80B14, B3, stainless steel
HV82PX63NI03-EFBN-RB3-D-OFIt features a gear ratio of 77.23:1 and a three-stage planetary design for reliable torque transmission. The input interface is 80B14 with a 19 mm input shaft, and the output hollow shaft diameter is 35 mm (Ø35H7).Constructed from stainless steel AISI 316L, the gear material ensures resistance to corrosion in washdown or hygienic environments. With an efficiency of 94% and BCD input/output of 100/130, this X63N unit is engineered for consistent, long-life operation in technical setups.
Specifications
Product description
Downloads
€3,255.00
In stock
Expected shipment:
Loading...
Accessories
More Information
IP classification
IP66
HS-Code
84834021.000000
Material
Stainless steel AISI 316L
Ratio
77,23:1
BCD input
100
BCD output
130
Gear stages
3
Efficiency (%)
94
Gear output shaft (mm)
35
Gear input shaft (mm)
19
Gear motor interface
80B14
Gear size
X63N
Output speed at 1400 RPM
18.1
Max output torque (Nm)
410
Max kW input at 1400 rpm
0.83
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description
Manufacturer Description: Clean-Geartech is a premium manufacturer specializing in hygienic and high-performance stainless steel gear solutions for demanding industrial applications. With a focus on durability, efficiency, and corrosion resistance, their gearboxes are engineered for reliability in food processing, pharmaceutical, chemical, and other hygiene-critical environments.Application-Focused Product Description:
High Gear Ratio of 77.23:1 enables precise speed reduction and torque multiplication, ideal for automation systems and machinery requiring high torque at low speeds.
Made entirely of AISI 316L stainless steel, including the housing, input/output shafts, and fasteners, it ensures superior corrosion resistance, making it perfect for applications in food & beverage, pharmaceutical, and offshore environments.
Ø35H7 hollow output shaft in stainless steel allows secure and backlash-free mounting with keyed shafts, simplifying integration in conveyor systems, mixers, and automated setups.
Three-stage bevel gear design delivers smooth and efficient torque transmission, extending gear life and supporting consistent operation under heavy or dynamic loads.
Compact gear size (X63N) and input shaft diameter of 19 mm make it suitable for space-restricted installations, such as filling lines, dosing pumps, or packaging machines.
Standardized motor interface (IEC 80B14) facilitates seamless integration with IEC flange motors, saving time during system integration and providing flexibility in drive selection.
Excellent mechanical efficiency of 94% reduces energy losses, lowering operating costs and maintaining performance consistency during continuous operation.
BCD input/output dimensions (100/130) allow for compatibility with a wide range of mechanical couplings, enabling use in modular systems and retrofitting scenarios.
Designed for washdown environments; suitable for CIP (Clean-In-Place) and SIP (Sterilize-In-Place) applications where hygiene is critical.This gearbox offers robust, hygienic performance for technical specialists and engineers seeking reliable power transmission in sensitive industrial environments.
High Gear Ratio of 77.23:1 enables precise speed reduction and torque multiplication, ideal for automation systems and machinery requiring high torque at low speeds.
Made entirely of AISI 316L stainless steel, including the housing, input/output shafts, and fasteners, it ensures superior corrosion resistance, making it perfect for applications in food & beverage, pharmaceutical, and offshore environments.
Ø35H7 hollow output shaft in stainless steel allows secure and backlash-free mounting with keyed shafts, simplifying integration in conveyor systems, mixers, and automated setups.
Three-stage bevel gear design delivers smooth and efficient torque transmission, extending gear life and supporting consistent operation under heavy or dynamic loads.
Compact gear size (X63N) and input shaft diameter of 19 mm make it suitable for space-restricted installations, such as filling lines, dosing pumps, or packaging machines.
Standardized motor interface (IEC 80B14) facilitates seamless integration with IEC flange motors, saving time during system integration and providing flexibility in drive selection.
Excellent mechanical efficiency of 94% reduces energy losses, lowering operating costs and maintaining performance consistency during continuous operation.
BCD input/output dimensions (100/130) allow for compatibility with a wide range of mechanical couplings, enabling use in modular systems and retrofitting scenarios.
Designed for washdown environments; suitable for CIP (Clean-In-Place) and SIP (Sterilize-In-Place) applications where hygiene is critical.This gearbox offers robust, hygienic performance for technical specialists and engineers seeking reliable power transmission in sensitive industrial environments.
