Clean-Geartech X62N, helical bevel gear Ø35H7 hollow shaft, 6,03:1, input 80B14, V5, stainless steel
HV82PX62NI01-EFBN-RV5-D-OFThis model delivers a gear ratio of 6.03:1 through 2 gear stages, offering an output efficiency of 96%. It features a Ø19 mm input shaft and a Ø35 mm output shaft, compatible with a 80B14 gear motor interface. Constructed with stainless steel AISI 316L gears, the gearbox ensures long-term performance in demanding environments. The gear size is X62N, and it incorporates a stainless steel Ø35H7 hollow output shaft for enhanced strength and hygiene-critical use. Input BCD is 100 mm, and output BCD is 130 mm.
Specifications
Product description
Downloads
€3,176.00
In stock
Expected shipment:
Loading...
Accessories
More Information
IP classification
IP66
HS-Code
84834021.000000
Material
Stainless steel AISI 316L
Ratio
6,03:1
BCD input
100
BCD output
130
Gear stages
2
Efficiency (%)
96
Gear output shaft (mm)
35
Gear input shaft (mm)
19
Gear motor interface
80B14
Gear size
X62N
Output speed at 1400 RPM
232
Max output torque (Nm)
240
Max kW input at 1400 rpm
6.1
Mounting position
V5
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description
Clean-Geartech is a premium manufacturer of hygienic, high-performance gearboxes designed for demanding industrial environments. Known for robust construction, corrosion resistance, and reliability, Clean-Geartech products are engineered specifically for sectors such as food processing, pharmaceuticals, marine, and chemical industries. Their gearboxes are built to meet stringent hygiene and performance standards, particularly where stainless steel is essential.Key features and application benefits of the Clean-Geartech X62N gear unit:
● Constructed from AISI 316L stainless steel, offering exceptional corrosion resistance, ideal for aggressive washdown environments in food, dairy, and pharmaceutical industries.
● Compact gear size X62N allows easy integration into machines and systems with space constraints.
● Gear ratio of 6.03:1 enables precise torque and speed control for a wide variety of automation and processing equipment.
● Output shaft Ø35H7 hollow format made from stainless steel (SS hollow shaft) allows direct shaft mounting without additional couplings, reducing system complexity and cost.
● High mechanical efficiency of 96% minimizes energy losses and ensures optimal power transmission in continuous operation equipment.
● Input flange 80B14 ensures compatibility with standard IEC motors, providing flexible drive configurations.
● Gear input shaft Ø19 mm designed for stable and vibration-resistant motor coupling in dynamic applications such as conveyors, mixers, or dosing systems.
● Two-stage bevel gear design delivers smooth and quiet torque transfer, suitable for robotics, packaging lines, and sensitive environments.
● Fully stainless steel housing mitigates bacterial contamination risks, compliant with strict hygiene regulations.
● Maintenance-friendly design and high durability reduce downtime and long-term service costs. This model is specifically optimized for high-demand technical environments where hygiene, durability, and performance are non-negotiable.
● Constructed from AISI 316L stainless steel, offering exceptional corrosion resistance, ideal for aggressive washdown environments in food, dairy, and pharmaceutical industries.
● Compact gear size X62N allows easy integration into machines and systems with space constraints.
● Gear ratio of 6.03:1 enables precise torque and speed control for a wide variety of automation and processing equipment.
● Output shaft Ø35H7 hollow format made from stainless steel (SS hollow shaft) allows direct shaft mounting without additional couplings, reducing system complexity and cost.
● High mechanical efficiency of 96% minimizes energy losses and ensures optimal power transmission in continuous operation equipment.
● Input flange 80B14 ensures compatibility with standard IEC motors, providing flexible drive configurations.
● Gear input shaft Ø19 mm designed for stable and vibration-resistant motor coupling in dynamic applications such as conveyors, mixers, or dosing systems.
● Two-stage bevel gear design delivers smooth and quiet torque transfer, suitable for robotics, packaging lines, and sensitive environments.
● Fully stainless steel housing mitigates bacterial contamination risks, compliant with strict hygiene regulations.
● Maintenance-friendly design and high durability reduce downtime and long-term service costs. This model is specifically optimized for high-demand technical environments where hygiene, durability, and performance are non-negotiable.
