Clean-Geartech X62N, helical bevel gear Ø35H7 hollow shaft, 37,57:1, input 80B14, V5, stainless steel
HV82PX62NI11-EFBN-RV5-D-OFThis unit features a gear size of X62N and a gear ratio of 37.57:1, operating with 2 gear stages and delivering a mechanical efficiency of 96%. The gear input shaft diameter is 19 mm, and the gear output shaft is a Ø35 mm H7 hollow shaft. The input interface complies with motor flange standard 80B14. The gear set is manufactured in stainless steel AISI 316L ensuring resistance to corrosion. The input BCD is 100 mm, while the output BCD is 130 mm, supporting reliable mechanical integration.
Specifications
Product description
Downloads
€3,176.00
In stock
Expected shipment:
Loading...
Accessories
More Information
IP classification
IP66
HS-Code
84834021.000000
Material
Stainless steel AISI 316L
Ratio
37,57:1
BCD input
100
BCD output
130
Gear stages
2
Efficiency (%)
96
Gear output shaft (mm)
35
Gear input shaft (mm)
19
Gear motor interface
80B14
Gear size
X62N
Output speed at 1400 RPM
37.3
Max output torque (Nm)
410
Max kW input at 1400 rpm
1.7
Mounting position
V5
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description
**Manufacturer:** Clean-GeartechClean-Geartech is a reputable manufacturer specialized in high-performance and hygienically designed gearboxes made from premium stainless steel materials. With strong expertise in corrosion-resistant transmission solutions, Clean-Geartech delivers reliable and high-efficiency products tailored to demanding industrial environments such as food processing, pharmaceuticals, and chemical manufacturing.**Technical Highlights and Application Benefits:**
• Constructed entirely from stainless steel AISI 316L, the housing and components offer outstanding corrosion resistance, ideal for washdown and aggressive environments.
• Equipped with a Ø35H7 stainless steel hollow output shaft (SS hollow shaft), allowing direct shaft-mounting and easy integration with driven equipment while ensuring hygiene.
• Bevel gear configuration provides precise torque transmission and high radial load capacity — well-suited for conveyor systems, mixers, and rotary applications.
• Gear ratio of 37.57:1 enables efficient speed reduction with torque amplification for high-torque, low-speed requirements in industrial automation processes.
• Compatible with standard IEC 80B14 motor interface, facilitating easy motor mounting and compatibility with a wide range of drive technologies.
• Compact X62N gear size with two-stage gearing increases structural robustness and improves torque distribution for heavy-duty, continuous operations.
• High mechanical efficiency of 96% ensures minimal energy losses and supports sustainable, energy-conscious machine design.
• Input shaft of 19 mm diameter allows for seamless integration with standard motor couplings and provides stable rotational input.
• Maintenance-friendly design reduces downtime and total cost of ownership, especially in environments requiring frequent cleaning and sanitation.
• Trusted by process engineers and maintenance specialists in food industry, chemical plants, and pharmaceutical production for its durability and compliance with hygienic standards.Maximize the performance of your drive applications with the Clean-Geartech X62N — engineered for durability and efficiency where hygiene and corrosion resistance are critical.
• Constructed entirely from stainless steel AISI 316L, the housing and components offer outstanding corrosion resistance, ideal for washdown and aggressive environments.
• Equipped with a Ø35H7 stainless steel hollow output shaft (SS hollow shaft), allowing direct shaft-mounting and easy integration with driven equipment while ensuring hygiene.
• Bevel gear configuration provides precise torque transmission and high radial load capacity — well-suited for conveyor systems, mixers, and rotary applications.
• Gear ratio of 37.57:1 enables efficient speed reduction with torque amplification for high-torque, low-speed requirements in industrial automation processes.
• Compatible with standard IEC 80B14 motor interface, facilitating easy motor mounting and compatibility with a wide range of drive technologies.
• Compact X62N gear size with two-stage gearing increases structural robustness and improves torque distribution for heavy-duty, continuous operations.
• High mechanical efficiency of 96% ensures minimal energy losses and supports sustainable, energy-conscious machine design.
• Input shaft of 19 mm diameter allows for seamless integration with standard motor couplings and provides stable rotational input.
• Maintenance-friendly design reduces downtime and total cost of ownership, especially in environments requiring frequent cleaning and sanitation.
• Trusted by process engineers and maintenance specialists in food industry, chemical plants, and pharmaceutical production for its durability and compliance with hygienic standards.Maximize the performance of your drive applications with the Clean-Geartech X62N — engineered for durability and efficiency where hygiene and corrosion resistance are critical.
