Description
Manufacturer Information:Clean-Geartech is a leading European manufacturer specializing in hygienic and corrosion-resistant drive solutions for demanding industrial environments. Their gearboxes are engineered for robustness, durability, and optimal efficiency, and are particularly suited to industries that demand cleanability and resistance to harsh chemicals, such as food processing, pharmaceuticals, and offshore applications.Key Features and Application Possibilities:
✔ Constructed from AISI 316L stainless steel – Offers superior resistance to corrosion and chemicals, making it ideal for industries such as food, beverage, pharmaceutical production, and marine applications.
✔ Hollow output shaft Ă˜25H7 in stainless steel – Allows for compact and hygienic integration with driven equipment; simplifies cleaning and reduces contamination risk in aseptic environments.
✔ Bevel gear design – Ensures precise and efficient transmission for right-angle motion applications; essential where space saving and direction change are required.
✔ Gear input shaft Ă˜11 mm with 63B14 motor interface – Provides standardized compatibility with IEC motors, enabling seamless assembly into existing automation systems.
✔ Three-stage reduction with a high gear ratio of 230.79:1 – Enables high torque output and low-speed operation suitable for heavy-duty conveying, mixers, lifting mechanisms, and actuator systems.
✔ Gear size X43N – Compact yet powerful configuration allows integration into limited-space machinery without compromising performance.
✔ 94% mechanical efficiency – High energy efficiency reduces heat generation and lowers energy consumption over time, contributing to optimized system operation.
✔ Smooth, crevice-free housing – Built for hygienic washdown and CIP (Clean-in-Place) processes, the gearbox prevents bacteria growth in clean-critical production environments.
✔ Maintenance-friendly and built for long service life – Designed with minimal wear components and sealed-for-life lubrication, reducing downtime and total cost of ownership.Clean-Geartech X43N gearboxes offer the perfect blend of performance, hygiene, and durability, making them the preferred choice for engineers designing tailored drive systems in sanitary and corrosion-sensitive industries.
✔ Constructed from AISI 316L stainless steel – Offers superior resistance to corrosion and chemicals, making it ideal for industries such as food, beverage, pharmaceutical production, and marine applications.
✔ Hollow output shaft Ă˜25H7 in stainless steel – Allows for compact and hygienic integration with driven equipment; simplifies cleaning and reduces contamination risk in aseptic environments.
✔ Bevel gear design – Ensures precise and efficient transmission for right-angle motion applications; essential where space saving and direction change are required.
✔ Gear input shaft Ă˜11 mm with 63B14 motor interface – Provides standardized compatibility with IEC motors, enabling seamless assembly into existing automation systems.
✔ Three-stage reduction with a high gear ratio of 230.79:1 – Enables high torque output and low-speed operation suitable for heavy-duty conveying, mixers, lifting mechanisms, and actuator systems.
✔ Gear size X43N – Compact yet powerful configuration allows integration into limited-space machinery without compromising performance.
✔ 94% mechanical efficiency – High energy efficiency reduces heat generation and lowers energy consumption over time, contributing to optimized system operation.
✔ Smooth, crevice-free housing – Built for hygienic washdown and CIP (Clean-in-Place) processes, the gearbox prevents bacteria growth in clean-critical production environments.
✔ Maintenance-friendly and built for long service life – Designed with minimal wear components and sealed-for-life lubrication, reducing downtime and total cost of ownership.Clean-Geartech X43N gearboxes offer the perfect blend of performance, hygiene, and durability, making them the preferred choice for engineers designing tailored drive systems in sanitary and corrosion-sensitive industries.
Specifications
IP classification
IP66
Country of origin
ITA
HS-Code
84834021.000000
ERP net weight (Kg)
23.200000
Material
Stainless steel AISI 316L
Ratio
230,79:1
BCD input
75
BCD output
90
Gear stages
3
Efficiency (%)
94
Gear output shaft (mm)
25
Gear input shaft (mm)
11
Gear motor interface
63B14
Gear size
X43N
Output speed at 1400 RPM
6.1
Max output torque (Nm)
136
Max kW input at 1400 rpm
0.09
Mounting position
V5
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834021
ERP net weight (Kg)
23.20
Country of origin
ITA
