Description
**Manufacturer Description:** Clean-Geartech is renowned for delivering highly durable and hygienic gear solutions tailored for demanding industrial environments. Their engineering excellence ensures reliable transmission solutions, especially where corrosion resistance and easy maintenance are required. **Key Features and Application Possibilities:**
Robust construction from stainless steel AISI 316L provides outstanding corrosion resistance, making it ideal for use in food processing, pharmaceutical, and chemical industries.
Worm gear design with a 67:1 ratio ensures high torque output at low speed, perfectly suited for conveyor systems, mixers, and lifting equipment requiring precise motion control.
Large 35 mm output shaft supports heavy duty loads and can be readily integrated into existing mechanical systems in industrial environments.
24 mm input shaft enables flexibility when coupling with various motor types; compatible with most standard industrial electric motors.
Efficiency rating of 65% offers an effective balance between performance and energy consumption in continuous operation scenarios.
Standardized 90B14 gear motor interface simplifies assembly, reducing integration time for OEMs and system builders.
SS (stainless steel) output shaft and housing guarantee longevity and resistance to harsh cleaning processes, supporting applications with strict hygiene requirements.
Gear size I85 and compact footprint allow space-saving installation even in machinery with limited space.
Designed for compatibility with B3 mounting and OF320 flange, providing flexibility in system integration and retrofitting. **With Clean-Geartech's worm gearbox, you are ensured maximum durability, optimal performance, and easy integration into sophisticated industrial systems.**
Robust construction from stainless steel AISI 316L provides outstanding corrosion resistance, making it ideal for use in food processing, pharmaceutical, and chemical industries.
Worm gear design with a 67:1 ratio ensures high torque output at low speed, perfectly suited for conveyor systems, mixers, and lifting equipment requiring precise motion control.
Large 35 mm output shaft supports heavy duty loads and can be readily integrated into existing mechanical systems in industrial environments.
24 mm input shaft enables flexibility when coupling with various motor types; compatible with most standard industrial electric motors.
Efficiency rating of 65% offers an effective balance between performance and energy consumption in continuous operation scenarios.
Standardized 90B14 gear motor interface simplifies assembly, reducing integration time for OEMs and system builders.
SS (stainless steel) output shaft and housing guarantee longevity and resistance to harsh cleaning processes, supporting applications with strict hygiene requirements.
Gear size I85 and compact footprint allow space-saving installation even in machinery with limited space.
Designed for compatibility with B3 mounting and OF320 flange, providing flexibility in system integration and retrofitting. **With Clean-Geartech's worm gearbox, you are ensured maximum durability, optimal performance, and easy integration into sophisticated industrial systems.**
Specifications
IP classification
IP66
Material
Stainless steel AISI 316L
Ratio
67:1
BCD input
115
BCD output
120
Efficiency (%)
65
Gear output shaft (mm)
35
Gear input shaft (mm)
24
Gear motor interface
90B14
Gear size
I85
Output speed at 1400 RPM
21
Max output torque (Nm)
289
Max kW input at 1400 rpm
0.97
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834025
ERP net weight (Kg)
23.30
Country of origin
ITA
