Description
Clean-Geartech is recognized for manufacturing premium-quality gear units, focused on delivering robust and hygienic solutions for demanding industrial applications. With specialized expertise in stainless steel gearing, their innovative designs provide high performance, reliability, and compliance with industry hygiene standards.
Highly resistant AISI 316L stainless steel housing provides exceptional corrosion resistance, making the gear ideal for food, pharmaceutical, and chemical applications where aggressive cleaning agents or washdown are common.
Worm gear configuration with a 20:1 ratio ensures precise torque control and smooth operation, ideal for conveyor drives, packaging machinery, and automation systems requiring speed reduction and torque multiplication.
Large 35 mm stainless steel hollow output shaft enables straightforward integration with various driven equipment and offers superior durability under heavy loads.
100/112B14 motor interface allows seamless mounting with standard IEC motors, granting flexibility for a wide range of electric motor options for diverse engineering projects.
Compact I85 size optimizes installation in restricted spaces, enhancing layout flexibility in machinery and processing lines.
28 mm input shaft supports robust power transmission and high input speeds, suiting demanding industrial processes.
High efficiency rating of 79% reduces energy losses, contributing to lower operating costs and improved system sustainability.
All external and functional surfaces are designed for easy cleaning, supporting strict hygiene requirements common to food and beverage, cosmetics, and pharmaceutical industries.
Suitable for continuous operation in harsh environments, thanks to both material and engineering quality, ensuring long operational life with minimal maintenance needs.
Highly resistant AISI 316L stainless steel housing provides exceptional corrosion resistance, making the gear ideal for food, pharmaceutical, and chemical applications where aggressive cleaning agents or washdown are common.
Worm gear configuration with a 20:1 ratio ensures precise torque control and smooth operation, ideal for conveyor drives, packaging machinery, and automation systems requiring speed reduction and torque multiplication.
Large 35 mm stainless steel hollow output shaft enables straightforward integration with various driven equipment and offers superior durability under heavy loads.
100/112B14 motor interface allows seamless mounting with standard IEC motors, granting flexibility for a wide range of electric motor options for diverse engineering projects.
Compact I85 size optimizes installation in restricted spaces, enhancing layout flexibility in machinery and processing lines.
28 mm input shaft supports robust power transmission and high input speeds, suiting demanding industrial processes.
High efficiency rating of 79% reduces energy losses, contributing to lower operating costs and improved system sustainability.
All external and functional surfaces are designed for easy cleaning, supporting strict hygiene requirements common to food and beverage, cosmetics, and pharmaceutical industries.
Suitable for continuous operation in harsh environments, thanks to both material and engineering quality, ensuring long operational life with minimal maintenance needs.
Specifications
IP classification
IP66
Material
Stainless steel AISI 316L
Ratio
20:1
BCD input
130
BCD output
120
Efficiency (%)
79
Gear output shaft (mm)
35
Gear input shaft (mm)
28
Gear motor interface
100/112B14
Gear size
I85
Output speed at 1400 RPM
70
Max output torque (Nm)
294
Max kW input at 1400 rpm
2.7
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834025
ERP net weight (Kg)
23.30
Country of origin
ITA
