calcPageSize())" />Clean-Geartech VFI I63, worm gear Ø25, 7:1, input 90B14, B3, OF320, stainless steel
HV82PI63UNIN010MFINN-TB3-E-OFThe Clean-Geartech VFI I63, worm gearbox Ø25, 7:1, input 90B14, B3, OF320, stainless steel is designed for demanding technical applications. With a gear ratio of 7:1 and efficiency of 83%, it offers reliable torque transmission. The gear input shaft diameter is 24 mm, and gear output shaft diameter is 25 mm. The gear size is I63. The input interface is 90B14. The gear motor mounting is B3. AISI 316L stainless steel gears ensure corrosion resistance and durability. The product supports BCD input 115 mm and BCD output 92 mm. Suitable for integration in environments requiring hygienic design and robust materials.
Specifications
Product description
Downloads
€1,550.00
Expected shipment:
Loading...
Estimated Shipping:
Estimate Shipping and Tax
Loading shipping methods...
Shipping Methods
No shipping methods available for this destination.
More Information
IP classification
IP66
Country of origin
ITA
HS-Code
84834025.000000
ERP net weight (Kg)
14.600000
Material
Stainless steel AISI 316L
Ratio
7:1
BCD input
115
BCD output
92
Efficiency (%)
83
Gear output shaft (mm)
25
Gear input shaft (mm)
24
Gear motor interface
90B14
Gear size
I63
Output speed at 1400 RPM
200
Max output torque (Nm)
125
Max kW input at 1400 rpm
3.2
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description

**Producer Description:** Clean-Geartech is renowned for delivering high-performance gear solutions built for demanding industrial applications. With a strong focus on hygiene, longevity, and reliability, Clean-Geartech components are trusted by engineers across the food processing, pharmaceutical, and chemical industries.**Key Features and Application Benefits:**
High-Quality AISI 316L Stainless Steel housing and components ensure superior resistance to corrosion, making it perfect for harsh washdown or chemically aggressive environments.
Stainless Steel output hollow shaft (Ø25 mm) increases longevity in demanding applications and allows for efficient, hygienic power transmission.
Integrated 90B14 motor interface enables easy compatibility with most standardized motor flange systems for flexible assembly.
Compact I63 gear size is space-saving, ideal for machinery with strict space constraints or modular system integration.
Optimized efficiency of 83% allows for improved energy savings and reduced operational costs over time in continuous-duty applications.
7:1 reduction ratio offers precise torque multiplication and speed reduction, suitable for conveyors, mixers, pumps, and automated handling systems.
B3 mounting configuration allows versatile installation in multiple orientations, supporting both OEM and retrofit deployments.
Robust input shaft (24 mm) supports high torque and ensures reliable drive connection even in heavy-load conditions.
Designed for demanding industries—especially food & beverage, pharmaceuticals, and chemicals—where hygiene, cleanability, and robustness are critical.Choose the Clean-Geartech VFI I63 for reliable, low-maintenance, and hygienic power transmission tailored to specialist industrial needs.
High-Quality AISI 316L Stainless Steel housing and components ensure superior resistance to corrosion, making it perfect for harsh washdown or chemically aggressive environments.
Stainless Steel output hollow shaft (Ø25 mm) increases longevity in demanding applications and allows for efficient, hygienic power transmission.
Integrated 90B14 motor interface enables easy compatibility with most standardized motor flange systems for flexible assembly.
Compact I63 gear size is space-saving, ideal for machinery with strict space constraints or modular system integration.
Optimized efficiency of 83% allows for improved energy savings and reduced operational costs over time in continuous-duty applications.
7:1 reduction ratio offers precise torque multiplication and speed reduction, suitable for conveyors, mixers, pumps, and automated handling systems.
B3 mounting configuration allows versatile installation in multiple orientations, supporting both OEM and retrofit deployments.
Robust input shaft (24 mm) supports high torque and ensures reliable drive connection even in heavy-load conditions.
Designed for demanding industries—especially food & beverage, pharmaceuticals, and chemicals—where hygiene, cleanability, and robustness are critical.Choose the Clean-Geartech VFI I63 for reliable, low-maintenance, and hygienic power transmission tailored to specialist industrial needs.
