Description
**Brand/Manufacturer: Clean-Geartech** Clean-Geartech is a reputable manufacturer specializing in advanced gear transmissions designed for demanding industrial sectors. Their products are renowned for premium quality, longevity, and innovation, particularly in applications requiring exceptional hygiene and corrosion resistance.
**Key Features & Application Advantages**
• Fully constructed from AISI 316L stainless steel, guaranteeing superior corrosion resistance and compliance with strict hygiene requirements, ideal for food, pharmaceutical, and chemical industries.• High protection against aggressive cleaning agents and environments, supporting reliable operation in washdown zones and harsh industrial areas.• Worm gear configuration with a 60:1 ratio delivers efficient torque multiplication, supporting precise, low-speed, and high-load applications.• 25 mm stainless steel output shaft enables robust, direct coupling to production equipment, conveyors, and processing lines.• 14 mm gear input shaft ensures compatibility with standard IEC 71B14 motor interfaces, resulting in straightforward integration and broad motor compatibility.• Gear size I50 provides a compact footprint suitable for space-restricted installations without compromising performance.• Efficiency rating of 58% ensures optimal energy usage in continuous-duty industrial settings.• Versatile mounting format (B3, OF320) supports various configurations in automations, robotic cells, or material handling systems.• Clean-Geartech's legacy guarantees reliable service with minimal maintenance, even in the most demanding technical environments.
**Key Features & Application Advantages**
• Fully constructed from AISI 316L stainless steel, guaranteeing superior corrosion resistance and compliance with strict hygiene requirements, ideal for food, pharmaceutical, and chemical industries.• High protection against aggressive cleaning agents and environments, supporting reliable operation in washdown zones and harsh industrial areas.• Worm gear configuration with a 60:1 ratio delivers efficient torque multiplication, supporting precise, low-speed, and high-load applications.• 25 mm stainless steel output shaft enables robust, direct coupling to production equipment, conveyors, and processing lines.• 14 mm gear input shaft ensures compatibility with standard IEC 71B14 motor interfaces, resulting in straightforward integration and broad motor compatibility.• Gear size I50 provides a compact footprint suitable for space-restricted installations without compromising performance.• Efficiency rating of 58% ensures optimal energy usage in continuous-duty industrial settings.• Versatile mounting format (B3, OF320) supports various configurations in automations, robotic cells, or material handling systems.• Clean-Geartech's legacy guarantees reliable service with minimal maintenance, even in the most demanding technical environments.
Specifications
IP classification
IP66
Material
Stainless steel AISI 316L
Ratio
60:1
BCD input
85
BCD output
75
Efficiency (%)
58
Gear output shaft (mm)
25
Gear input shaft (mm)
14
Gear motor interface
71B14
Gear size
I50
Output speed at 1400 RPM
23
Max output torque (Nm)
62
Max kW input at 1400 rpm
0.26
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834025
ERP net weight (Kg)
7.30
Country of origin
ITA
