Clean-Geartech VFI I50, worm gear Ø25, 18:1, input 80B14, B3, OF320, stainless steel

HV82PI50UNIN040MFINN-RB3-D-OF

The Clean-Geartech VFI I50, worm gearbox Ø25, 18:1, input 80B14, B3, OF320, stainless steel features several key attributes designed for demanding applications. It offers a BCD input of 100 mm and a BCD output of 75 mm. The efficiency is 75%. The gear input shaft diameter is 19 mm, while the gear output shaft diameter is 25 mm. Constructed from stainless steel AISI 316L, the gears ensure corrosion resistance and durability. The gear motor interface is 80B14. With a ratio of 18:1 and a gear size designation of I50, this gearbox is suitable for robust technical environments.

Specifications

Product description

Downloads

Excluded taxes and delivery costs

Expected shipment:

Estimated Shipping:

More Information

IP classification

IP66

Country of origin

ITA

HS-Code

84834025.000000

ERP net weight (Kg)

7.300000

Material

Stainless steel AISI 316L

Ratio

18:1

BCD input

100

BCD output

Efficiency (%)

Gear output shaft (mm)

Gear input shaft (mm)

Gear motor interface

80B14

Gear size

I50

Output speed at 1400 RPM

Max output torque (Nm)

Max kW input at 1400 rpm

0.67

Mounting position

Oil

Mobil SHC Cibus 320 NSF H1

Producer

Clean-Geartech

Description

Clean-Geartech is a leading manufacturer specializing in high-performance, corrosion-resistant gear technologies, designed to meet rigorous hygiene and durability standards required by the food, pharmaceutical, and chemical industries. Their advanced engineering focuses on reliability, longevity, and operational efficiency.
**Product: Clean-Geartech VFI I50, Worm Gear Ø25, 18:1, Input 80B14, B3, OF320, Stainless Steel** **Key Features, Benefits, and Applications:**
Constructed entirely from AISI 316L stainless steel, providing superior corrosion resistance in aggressive and hygiene-critical environments

Worm gear with a 25 mm stainless steel output shaft for maximum strength and reliability during high-torque industrial applications

Input shaft diameter of 19 mm, compatible with a wide range of standard industrial motors and configurations

Gear motor interface 80B14 ensures flexible and efficient integration with IEC-standard motors used in automated systems

18:1 gear ratio delivers precise speed reduction and optimal torque multiplication for demanding conveyor, mixer, and process equipment applications

Efficiency of 75% supports energy savings and lower running costs for continuous operation

Enclosed, maintenance-friendly design suits washdown environments in food, beverage, and pharmaceutical production lines

Available in compact Gear size I50, ideal for installation in space-constrained machinery and modular systems

Rugged build supports high load capacity and operational reliability in heavy-duty applications

Meets industry certifications for hygiene and robustness, supporting compliance in regulated sectors (EHEDG, FDA, etc.)
