calcPageSize())" />Clean-Geartech VFI I11, worm gear Ø42, 38:1, input 100/112B14, B3, OF320, stainless steel
HV82PI11UNIN070MMINN-UB3ST-OFThe Clean-Geartech VFI I11 worm gear, Ø42, 38:1, input 100/112B14, B3, OF320, stainless steel is designed for demanding industrial applications. It offers a BCD input of 130, BCD output of 140, and an efficiency of 75%. The gear input shaft measures 28 mm and the gear output shaft measures 42 mm. Constructed with gear material in stainless steel AISI 316L, it ensures corrosion resistance and durability. The gear motor interface is 100/112B14 and the gear size is I11. The ratio is 38:1, suitable for controlled speed and torque output.
Specifications
Product description
Downloads
€3,389.00
Expected shipment:
Loading...
Estimated Shipping:
Estimate Shipping and Tax
Loading shipping methods...
Shipping Methods
No shipping methods available for this destination.
More Information
IP classification
IP66
Country of origin
ITA
HS-Code
84834025.000000
ERP net weight (Kg)
38.500000
Material
Stainless steel AISI 316L
Ratio
38:1
BCD input
130
BCD output
140
Efficiency (%)
75
Gear output shaft (mm)
42
Gear input shaft (mm)
28
Gear motor interface
100/112B14
Gear size
I11
Output speed at 1400 RPM
37
Max output torque (Nm)
641
Max kW input at 1400 rpm
3.3
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description

**Brand Description:** Clean-Geartech is recognized for its high-quality gear solutions, specializing in stainless steel gear drives engineered for demanding industrial and hygienic environments. The company’s products are trusted by engineers across sectors such as food processing, pharmaceuticals, chemical production, and marine applications for their long-term durability, corrosion resistance, and reliable performance.**Key Features, Advantages, and Applications:**
High-Grade AISI 316L Stainless Steel Construction: Ensures outstanding corrosion resistance, ideal for harsh and hygienic environments such as food, beverage, marine, and pharmaceutical industries.
42 mm Stainless Steel Output Shaft: Facilitates high torque transmission and enables integration with a wide array of industrial equipment.
Worm Gear Ratio 38:1: Delivers high output torque and significant speed reduction, making it suitable for conveyor drives, mixing equipment, and automated actuator solutions.
Gear Motor Interface 100/112B14: Allows flexible mounting with standard IEC motors, simplifying system integration and minimizing installation time.
Input Shaft Diameter 28 mm: Accommodates robust power input for heavy-duty operations across industrial settings.
75% Mechanical Efficiency: Provides reliable power transfer while reducing energy losses, contributing to lower operational costs.
Gear Size I11: Compact yet powerful, fitting space-constrained systems while maintaining high performance.
Fully Enclosed Housing: Optimized for washdown areas, supporting clean-in-place (CIP) procedures in hygiene-critical industries.
Versatile Applications: Used in automated food lines, pharmaceutical packaging, stainless steel conveyors, mixing vats, marine vessel equipment, and aggressive chemical processing environments.
High-Grade AISI 316L Stainless Steel Construction: Ensures outstanding corrosion resistance, ideal for harsh and hygienic environments such as food, beverage, marine, and pharmaceutical industries.
42 mm Stainless Steel Output Shaft: Facilitates high torque transmission and enables integration with a wide array of industrial equipment.
Worm Gear Ratio 38:1: Delivers high output torque and significant speed reduction, making it suitable for conveyor drives, mixing equipment, and automated actuator solutions.
Gear Motor Interface 100/112B14: Allows flexible mounting with standard IEC motors, simplifying system integration and minimizing installation time.
Input Shaft Diameter 28 mm: Accommodates robust power input for heavy-duty operations across industrial settings.
75% Mechanical Efficiency: Provides reliable power transfer while reducing energy losses, contributing to lower operational costs.
Gear Size I11: Compact yet powerful, fitting space-constrained systems while maintaining high performance.
Fully Enclosed Housing: Optimized for washdown areas, supporting clean-in-place (CIP) procedures in hygiene-critical industries.
Versatile Applications: Used in automated food lines, pharmaceutical packaging, stainless steel conveyors, mixing vats, marine vessel equipment, and aggressive chemical processing environments.
