Description
Clean-Geartech is a renowned manufacturer specializing in high-performance, hygienic drive solutions for demanding industrial environments. Their products are known for superior durability, corrosion resistance, and premium engineering tailored for food, pharmaceutical, chemical, and other process industries.
Key features and applications:
High-efficiency worm gearbox with 23:1 ratio, enabling precise speed reduction and optimized torque transfer for conveyor systems, mixers, and dosing equipment
Gear material constructed from AISI 316L stainless steel ensures excellent corrosion resistance suited for washdown and aggressive chemical environments, maximizing service life and minimizing maintenance
Output shaft diameter of 42 mm (SS hollow shaft) for reliable and hygienic power transmission in automated filling lines, packaging, and handling systems
Input shaft size 28 mm with a standardized 100/112B14 flange interface for seamless integration with IEC motors in diverse industrial machinery
80% mechanical efficiency delivers robust power with minimal energy loss, significantly improving system output and reducing operational costs in continuous-duty applications
Compact I11 gear size offers flexible installation in confined spaces, supporting efficient layouts for OEMs and retrofit projects
Rated for aggressive industrial cleaning due to stainless steel construction—ideal for industries subject to strict hygiene regulations and potential chemical exposure
Clean, smooth design eliminates dirt traps and facilitates quick sanitation processes, reducing contamination risks on food processing and pharmaceutical lines
Advanced sealing and construction minimize lubricant leakage, supporting cleanroom production and food-safe operation
Key features and applications:
High-efficiency worm gearbox with 23:1 ratio, enabling precise speed reduction and optimized torque transfer for conveyor systems, mixers, and dosing equipment
Gear material constructed from AISI 316L stainless steel ensures excellent corrosion resistance suited for washdown and aggressive chemical environments, maximizing service life and minimizing maintenance
Output shaft diameter of 42 mm (SS hollow shaft) for reliable and hygienic power transmission in automated filling lines, packaging, and handling systems
Input shaft size 28 mm with a standardized 100/112B14 flange interface for seamless integration with IEC motors in diverse industrial machinery
80% mechanical efficiency delivers robust power with minimal energy loss, significantly improving system output and reducing operational costs in continuous-duty applications
Compact I11 gear size offers flexible installation in confined spaces, supporting efficient layouts for OEMs and retrofit projects
Rated for aggressive industrial cleaning due to stainless steel construction—ideal for industries subject to strict hygiene regulations and potential chemical exposure
Clean, smooth design eliminates dirt traps and facilitates quick sanitation processes, reducing contamination risks on food processing and pharmaceutical lines
Advanced sealing and construction minimize lubricant leakage, supporting cleanroom production and food-safe operation
Specifications
IP classification
IP66
Material
Stainless steel AISI 316L
Ratio
23:1
BCD input
130
BCD output
140
Efficiency (%)
80
Gear output shaft (mm)
42
Gear input shaft (mm)
28
Gear motor interface
100/112B14
Gear size
I11
Output speed at 1400 RPM
61
Max output torque (Nm)
515
Max kW input at 1400 rpm
4.1
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834025
ERP net weight (Kg)
38.50
Country of origin
ITA
