calcPageSize())" />Clean-Geartech VFI I11, worm gear Ø42, 16:1, input 100/112B14, B3, OF320, stainless steel
HV82PI11UNIN030MMINN-UB3ST-OFThe Clean-Geartech VFI I11, worm gear Ø42, 16:1, input 100/112B14, B3, OF320, stainless steel is designed for demanding technical environments. This unit features a BCD input of 130 and a BCD output of 140. It delivers 82% efficiency. The gear input shaft diameter is 28 mm and the gear output shaft diameter is 42 mm. The gear motor interface supports 100/112B14. The gear size is I11 with a ratio of 16:1. With gears made from AISI 316L stainless steel, this gearbox supports demanding industrial and hygienic applications.
Specifications
Product description
Downloads
€3,389.00
Expected shipment:
Loading...
Estimated Shipping:
Estimate Shipping and Tax
Loading shipping methods...
Shipping Methods
No shipping methods available for this destination.
More Information
IP classification
IP66
Country of origin
ITA
HS-Code
84834025.000000
ERP net weight (Kg)
38.500000
Material
Stainless steel AISI 316L
Ratio
16:1
BCD input
130
BCD output
140
Efficiency (%)
82
Gear output shaft (mm)
42
Gear input shaft (mm)
28
Gear motor interface
100/112B14
Gear size
I11
Output speed at 1400 RPM
88
Max output torque (Nm)
536
Max kW input at 1400 rpm
6
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Description

**Brand Description:** Clean-Geartech is a leading manufacturer specializing in premium stainless steel gear solutions tailored for demanding industrial applications. Their focus on hygienic design, robust performance, and corrosion resistance makes their products ideal for the food, pharmaceutical, and chemical industries.**Key Product Features, Benefits, and Applications:**
Robust, corrosion-resistant housing and components manufactured from AISI 316L stainless steel ensure maximum durability and longevity, even in aggressive environments.
16:1 gear ratio enables precise speed reduction and high torque transmission, supporting applications requiring controlled motion.
Large Ø42 mm output shaft made from stainless steel allows for efficient power transfer, high-load capacity, and direct coupling to driven equipment such as conveyors, mixers, and pumps.
Compatible with IEC 100/112B14 gear motor interface, ensuring broad adaptability to standard industrial motors and simplifying integration into existing systems.
High efficiency rating of 82% achieves lower energy consumption, making the operation cost-effective and environmentally friendly.
Compact I11 gear size and 28 mm input shaft facilitate installation where space is limited and maintain system design flexibility.
Stainless steel hollow shaft options offer hygienic design ideal for washdown environments in food processing, pharmaceuticals, and cleanroom machinery.
Designed for reliability and minimal maintenance, reducing downtime and long-term operating costs in critical automation and production systems.
Robust, corrosion-resistant housing and components manufactured from AISI 316L stainless steel ensure maximum durability and longevity, even in aggressive environments.
16:1 gear ratio enables precise speed reduction and high torque transmission, supporting applications requiring controlled motion.
Large Ø42 mm output shaft made from stainless steel allows for efficient power transfer, high-load capacity, and direct coupling to driven equipment such as conveyors, mixers, and pumps.
Compatible with IEC 100/112B14 gear motor interface, ensuring broad adaptability to standard industrial motors and simplifying integration into existing systems.
High efficiency rating of 82% achieves lower energy consumption, making the operation cost-effective and environmentally friendly.
Compact I11 gear size and 28 mm input shaft facilitate installation where space is limited and maintain system design flexibility.
Stainless steel hollow shaft options offer hygienic design ideal for washdown environments in food processing, pharmaceuticals, and cleanroom machinery.
Designed for reliability and minimal maintenance, reducing downtime and long-term operating costs in critical automation and production systems.
