**Brand/Manufacturer:**
Produced by Clean-Geartech, a leading manufacturer specializing in high-performance stainless steel gear solutions for demanding industrial environments. Clean-Geartech is known for exceptional reliability, precision engineering, and hygienic design suitable for rigorous applications.**Key Features, Benefits & Application Possibilities:**
Constructed from AISI 316L stainless steel, the gear housing and components provide outstanding corrosion resistance and durability for environments with aggressive cleaning, such as food, beverage, pharmaceutical, and chemical industries.
Stainless steel through (hollow) output shaft (Ø25 mm) offers robust and hygienic power transmission for shaft-mounted applications and easy integration into conveying, packaging, or processing lines.
Compact N50 size and integrated IEC 63B14 motor interface ensure rapid and reliable coupling with standard motors, supporting modularity and simplified replacement in maintenance-critical operations.
Precise 10:1 ratio delivers accurate speed reduction and high torque, ideal for mixers, conveyors, and automated machinery where torque control and smooth motion are crucial.
High efficiency (up to 80 %) results in reduced energy losses and heat generation, minimizing operational costs and enabling continuous-duty operation even in energy-sensitive environments.
Both gear input shaft (Ø11 mm) and the gear set itself are made of AISI 316L stainless steel, assuring long-term operation, resistance to wear, and suitability for washdown or high-humidity conditions.
Suited for demanding technical applications, including robotics, automation systems, bulk material handling, and process manufacturing requiring both hygiene and endurance.
Produced by Clean-Geartech, a leading manufacturer specializing in high-performance stainless steel gear solutions for demanding industrial environments. Clean-Geartech is known for exceptional reliability, precision engineering, and hygienic design suitable for rigorous applications.**Key Features, Benefits & Application Possibilities:**
Constructed from AISI 316L stainless steel, the gear housing and components provide outstanding corrosion resistance and durability for environments with aggressive cleaning, such as food, beverage, pharmaceutical, and chemical industries.
Stainless steel through (hollow) output shaft (Ø25 mm) offers robust and hygienic power transmission for shaft-mounted applications and easy integration into conveying, packaging, or processing lines.
Compact N50 size and integrated IEC 63B14 motor interface ensure rapid and reliable coupling with standard motors, supporting modularity and simplified replacement in maintenance-critical operations.
Precise 10:1 ratio delivers accurate speed reduction and high torque, ideal for mixers, conveyors, and automated machinery where torque control and smooth motion are crucial.
High efficiency (up to 80 %) results in reduced energy losses and heat generation, minimizing operational costs and enabling continuous-duty operation even in energy-sensitive environments.
Both gear input shaft (Ø11 mm) and the gear set itself are made of AISI 316L stainless steel, assuring long-term operation, resistance to wear, and suitability for washdown or high-humidity conditions.
Suited for demanding technical applications, including robotics, automation systems, bulk material handling, and process manufacturing requiring both hygiene and endurance.
Specifications
IP classification
IP66
Material
Stainless steel AISI 316L
Ratio
10:1
BCD input
75
BCD output
94
Efficiency (%)
80
Gear output shaft (mm)
25
Gear input shaft (mm)
11
Gear motor interface
63B14
Gear size
N50
Output speed at 1400 RPM
140
Max output torque (Nm)
62
Max kW input at 1400 rpm
1.1
Mounting position
B3
Oil
Mobil SHC Cibus 320 NSF H1
Producer
Clean-Geartech
Foreign trade
HS-Code
84834025
ERP net weight (Kg)
10.00
Country of origin
ITA
