Clean-Geartech is an acclaimed manufacturer renowned for high-precision gearbox solutions designed specifically for demanding industrial applications. With a focus on hygiene, durability, and performance, Clean-Geartech products are trusted by engineers and technical specialists across industries such as food processing, pharmaceuticals, chemicals, and marine environments.Key Features and Application Benefits:
Stainless Steel (AISI 316L) Gear Housing – Ensures exceptional corrosion resistance, ideal for hygienic and harsh environments such as food production, pharmaceuticals, and chemical processing.

Hollow Output Shaft Ø18 mm – Provides a compact and flexible connection for direct coupling to driven equipment, reducing misalignment and minimizing the need for additional couplings.

Gear Ratio 60:1 – Offers high torque output at low speeds, suitable for applications requiring precise movement and controlled mechanical advantage, such as conveyors or mixers.

Input Shaft Ø14 mm – Designed to interface seamlessly with compact motors, supporting precision alignment and consistent power transmission.

Motor Interface B14 Size 71 – Compatible with IEC standard motors, enabling streamlined integration with existing drive systems and simplifying installation procedures.

Efficiency at 56% – While typical for worm gear technology, this design efficiency promotes smooth operation for tasks where torque is prioritized over speed and energy losses are less critical.

Gear Size N45 – Compact form factor for space-constrained installations while still providing reliable mechanical performance under moderate load conditions.

BCD Input 85 mm & BCD Output 65 mm – Standard bolt circle dimensions ensure easy mechanical integration with compatible components and mounting systems.
Applications:
Optimally suited for environments requiring frequent washdowns and strict hygiene standards such as food, beverage, and pharmaceutical production lines.

Excellent for automated systems in marine and offshore industries due to high corrosion resistance of stainless steel parts including SS hollow shaft.

Ideal for general industrial automation where space constraints and torque requirements favor worm gear configurations, including packing systems, dosing equipment or mechanical actuators.
