Clean-Geartech is a premium manufacturer of hygienic, corrosion-resistant transmission solutions developed specifically for demanding industrial applications. Renowned for their durable construction and use of high-grade materials such as AISI 316L stainless steel, Clean-Geartech products are ideal for sectors requiring uncompromised cleanliness, reliability and resistance to harsh environments—such as food, pharmaceutical, chemical, and marine industries.Key Features and Application Benefits:
High-grade AISI 316L stainless steel housing ensures superior corrosion resistance, making the gear unit ideal for washdown applications in food processing, pharmaceuticals, and offshore installations.

The worm gear design with a 37:1 reduction ratio offers excellent torque multiplication for low-speed, high-load applications, such as conveyors, mixers, and dosing systems.

Integrated 63B14 motor interface allows for easy and standardized coupling with most IEC motors, simplifying integration and reducing installation time.

Output shaft diameter of Ø18 mm in stainless steel (SS output shaft) ensures robustness and compatibility with various driven components under high static and dynamic loads.

Compact N45 gear size optimizes space utilization, making the gearbox suitable for installations with limited mounting space, while still delivering high-performance torque output.

Input shaft diameter Ø11 mm accommodates a wide range of motor coupling solutions, increasing design flexibility for engineers and system integrators.

Operational efficiency at 63% ensures acceptable thermal behavior and optimized energy transfer, which is critical in automated systems requiring consistent performance.

Specially engineered for environments where hygiene and chemical resistance are non-negotiable, significantly extending service life and minimizing maintenance interventions.

Ideal for integration into modular machine designs where CIP (clean-in-place) and SIP (sterilize-in-place) practices are common.
