Busck AC Motor T2A71B-4B5 – 0.37 kW, 1400 RPM, B5 Flange, Aluminium
T2A71B-4B5The Busck AC Motor T2A71B-4B5 is a 0.37 kW electric motor delivering 1400 RPM at rated speed. It features a B5 flange mounting and is constructed with a durable aluminium housing. Designed according to IEC frame size 71 and compliant with the IE2 efficiency standard, this motor offers reliable operation for industrial applications. It has a shaft diameter of Ø14 mm and operates with a voltage connection of 230/400 V. The motor uses TEFC cooling and provides IP55 protection for use in demanding environments. It is built with 4 poles and has a BCD of 85 mm. Produced by Busck.
Specifications
Product description
Downloads
€298.00
Made to order
Expected shipment:
Loading...
More Information
IP classification
IP 55
Model
T2A71B-4B5
Speed (RPM)
1400
Rated output (kW)
0.37
Efficiency (% FL)
72.7
Voltage connection (Δ/Y)
230/400
Rated current at voltage
1.76/1.01
Nominal torque (Nm)
2.52
Start current ratio (IA/IN)
4.7
Mounting
B5
BCD
85
Poles
4
Efficiency standard
IE2
Shaft diameter (mm)
Ø14
Cooling
TEFC
HS-Code
85015100.000000
Description
Key features:
- IP55 rating: The motor is dust and water-resistant, making it suitable for use in demanding conditions.
- High power output: With a power rating of 0.37kW, this motor delivers performance and efficiency.
- Speed control: Capable of operating at 1400RPM, ensuring precise speed control for various applications.
- Voltage compatibility: Supports dual voltage operation at 230V or 400V, making it adaptable to different power systems.
- B5 flange mounting: The B5 flange allows for easy and secure installation.
- IE2 efficiency: Designed with high energy efficiency, leading to reduced energy consumption and operating costs.
Specifications:
- Robust construction: Built with aluminum.
- Wide temperature range: -20°C to +40°C.
