T3CR225M-2B35

The Busck AC Motor T3CR225M-2B35 is a reliable electric motor designed for industrial use, built according to the IEC 225 standard and classified with IP55 protection. This model delivers a rated output of 45 kW with a rated speed of 2800 RPM and a maximum speed of 2950 RPM. It operates at 400/690 V, 50 Hz, and meets the IE3 efficiency standard. The motor features a TEFC (Totally Enclosed Fan Cooled) design and is constructed from aluminium for a balance of weight and durability. The B35 mounting type and Ø55 mm shaft diameter ensure compatibility with a wide range of systems. This 2-pole electric motor has a BCD of 500 mm for secure installation.

Specifications

Product description

Downloads

Excluded taxes and delivery costs

Made to order

Expected shipment:

More Information

IP classification

IP 55

Model

T3CR225M-2B35

Speed (RPM)

2950

Rated output (kW)

Efficiency (% FL)

Voltage connection (Δ/Y)

400/690

Rated current at voltage

75.9/43.7

Nominal torque (Nm)

145.68

Start current ratio (IA/IN)

8.5

Mounting

B35

BCD

500

Poles

Efficiency standard

IE3

Shaft diameter (mm)

Ø55

Cooling

TEFC

HS-Code

85015220.000000

Description

Key features:

High efficiency: The motor boasts an IE3 energy efficiency rating, promoting cost savings and reduced energy consumption.
IP55 rating: Provides protection against dust and water ingress, making it suitable for various indoor and outdoor installations.
Powerful performance: With a power output of 45kW and a speed of 2950RPM, this motor delivers performance to meet industrial needs.
Flexible voltage: The motor supports a voltage range of 400/690V.
B35 flange: Equipped with a B35 flange, facilitating easy mounting and integration into various machinery setups.

Specifications:
