T3CR180L-6B3

The Busck AC motor T3CR180L-6B3 is a three-phase electric motor designed for industrial applications. It features a rated output of 15 kW and operates at a speed of 960 RPM, with a rated speed of 900 RPM. The motor is built in accordance with IEC size 180 and complies with the IE3 energy efficiency standard. It has a B3 foot mounting configuration and is enclosed in an aluminium housing with TEFC (Totally Enclosed Fan Cooled) cooling. The motor includes 6 poles and has a shaft diameter of Ø48 mm. It supports a voltage connection of 400/690V at 50 Hz and is rated to IP55 for ingress protection.

Specifications

Product description

Downloads

Excluded taxes and delivery costs

Made to order

Expected shipment:

More Information

IP classification

IP 55

Model

T3CR180L-6B3

Speed (RPM)

960

Rated output (kW)

Efficiency (% FL)

91.2

Voltage connection (Δ/Y)

400/690

Rated current at voltage

30.1/17.3

Nominal torque (Nm)

149.22

Start current ratio (IA/IN)

Mounting

Poles

Efficiency standard

IE3

Shaft diameter (mm)

Ø48

Cooling

TEFC

HS-Code

85015220.000000

Description

Key features:

Weatherproof design: With an IP55 rating, the motor is well-protected against dust and water ingress.
High power output: The motor packs an 15kW power rating, ensuring it can handle challenging tasks with ease.
Optimal speed: Operating at 960RPM.
High energy efficiency: Rated as IE3, this motor meets stringent energy efficiency standards.
Voltage options: The Busck motor offers flexibility with voltage compatibility at 400/690V.
Mounting flange: Featuring a B3 flange design, the motor allows easy and secure mounting.

Specifications:
