calcPageSize())" />Clean Geartech AC motor TENV71A-6, 0,18kW, 890RPM, B14, 230/400, Aluminium
HV82APMCKD6JTENN4KCR2-N---NNNThe Clean Geartech TENV71A-6 is a robust 0.18 kW AC motor, precision-engineered in corrosion-resistant aluminium for hygiene-critical environments that demand consistent, low-speed performance. Operating at 890 RPM with 6 poles, it delivers a dependable 1.95 Nm torque, ideal for dosing systems, slow conveyors, or mixing applications where gentle, controlled motion is crucial. The IP69K enclosure guarantees complete protection against dust, powerful water jets, and steam cleaning — perfect for installations in food, beverage, and pharmaceutical industries with rigorous washdown protocols. Its Totally Enclosed Non-Ventilated (TENV) cooling system eliminates external airflow, minimizing contamination risks and ensuring smooth operation in clean environments. Rated to the superior IE4 efficiency class, it helps reduce long-term energy costs and supports sustainability targets. Designed for IEC 71 frame mounting with a Ø14 mm shaft, it integrates easily into standard systems. Certified to UL and cURus standards and equipped with PTO thermal protection, this motor provides a reliable, low-maintenance drive solution that safeguards your process uptime and product quality.
Made to order
Expected shipment:
More Information
Description

Key Features:
- IP 69K protection: Keeps the motor safe from dust and water ingress.
- Energy-efficient design: IE4 classification reduces power consumption.
- Sturdy Aluminium construction: Ensures longevity and corrosion resistance.
- Reliable output: Generates 0.18 kW power for industrial applications.
- Cooling system: Equipped with Totally Enclosed Non Ventilated (TENV) cooling for effective temperature control.
- Thermal protection: Includes PTO for extended motor life.
Specifications:
- Model: TENV71A-6
- Power Output: 0.18 kW
- Nominal Torque: 1.95 Nm
- Efficiency Rating: 70.2%
- Starting Current Ratio: 3.0
- Certifications: UL, cURus
