BEGE flange encoder MN-120-19-00027, 2 pulses, 2m cable, aluminium
HV500140The MN-120-19-00207 incremental encoder is tailored for IEC 80B14 motors, offering 2 pulses per revolution for simple speed detection or on/off feedback in basic automation environments. It features a solid Ø19 mm shaft, a Ø120 mm outer diameter, and a 7 mm flange thickness, mounted via a 100 mm bolt circle (BCD). The robust aluminium housing is certified to IP55, ensuring protection against dust ingress and water spray. A 2.0 m cable is included for direct wiring into control systems.
Made to order
Expected shipment:
More Information
Description
Key features:
- Magnetic rotary encoder for accurate and reliable signal measurement.
- High signal quality and precise processing for enhanced performance.
- Compatible with IEC standard electric motors, ensuring seamless integration.
- Stable contactless signal measurement for improved durability.
- The standard IP55 rating can reach IP67 with the proper sealant between the motor and machine flange.
- Intermediate flange design eliminates the need for an extended fan cover.
Specifications:
- For motorsize: B14.
- Temperature range: -30°C to +80°C.
Materials:
- Flange: Made from durable aluminum.
- Hub: Constructed from stainless steel.
